Product Details:
|
| Name: | Vibrating Fluidized Bed Dryer | Capacity: | 100-130kg/h Water Evaporation |
|---|---|---|---|
| Heat Source: | Gas Or Electric Or Steam Heating | Application: | Chemical, Pharmaceutical, Food, Dehydrated Vegetables, Food, Minerals And Other Industries Powder, Granular Materials, Dry, Cooling And Other Operations |
| Warranty: | 1 Year | Condition: | New |
| Voltage: | 220v-450v | Type: | Fluid Bed Drying Equipment |
| High Light: | Vibrating Fluid Bed Dryer Machine,Fluid Bed Dryer Machine 6*0.6m,3.6m2 vibrating bed dryer |
||
Vibrating fluidized bed drying equipment for dihydro-ammonia granules
Vibrating Fluidized Bed Dryer
The scope of application:
1. Food: chicken essence, seafood essence, monosodium glutamate, citric acid, xylitol, maltitol, sorbitol, dehydrated vegetables, calcium lactate, wine tank, monosodium glutamate, sugar, salt, slag, watercress, seeds, etc.
2. Pharmaceutical and chemical industry: various tableting granules, ammonium sulfate, thiourea dioxide, NOBS, boric acid, borax, diphenol, malic acid, maleic acid, etc.
3. It can also be used for cooling and humidification of materials.
Features:
1. The material is heated evenly, the heat exchange is sufficient, the drying intensity is high, and the energy saving is about 30% compared with the ordinary dryer.
2. The vibration source is driven by a vibration motor, with stable operation, convenient maintenance, low noise and long service life.
3. The fluidization is stable, and there is no dead angle and blow-through phenomenon.
4. Good adjustability, adaptable to face width.
5. It has little damage to the surface of the material, and can be used for drying of fragile materials. It does not affect the working effect when the material particles are irregular.
6. The fully enclosed structure effectively prevents cross-contamination between materials and air, and the working environment is clean.
Technical parameters
| Model | Area of fluidi bed(㎡) | Temperature of inlet air(℃) | Temperature of outlet air(℃) | Water evaporation capacity (kg/h) | Motor Power(kW) | Weight (kg) |
| WKS-FBD-3*0.3 | 0.9 | 70-140 | 40-70 | 20-35 | 0.8*2 | 1250 |
| WKS-FBD-4.5*0.3 | 1.35 | 70-140 | 40-70 | 35-50 | 0.8*2 | 1250 |
| WKS-FBD-4.5*0.45 | 2.025 | 70-140 | 40-70 | 50-70 | 1.1*2 | 1670 |
| WKS-FBD-4.5*0.6 | 2.7 | 70-140 | 40-70 | 70-90 | 1.1*2 | 1670 |
| WKS-FBD-6*0.45 | 2.7 | 70-140 | 40-70 | 80-100 | 1.5*2 | 2100 |
| WKS-FBD-6*0.6 | 3.6 | 70-140 | 40-70 | 100-130 | 1.5*2 | 2400 |
| WKS-FBD-6*0.75 | 4.5 | 70-140 | 40-70 | 120-140 | 2.2*2 | 2840 |
| WKS-FBD-6*0.9 | 5.4 | 70-140 | 40-70 | 140-170 | 2.2*2 | 3160 |
| WKS-FBD-7.5*0.75 | 5.625 | 70-140 | 40-70 | 150-180 | 2.2*2 | 3200 |
| WKS-FBD-7.5*0.9 | 6.75 | 70-140 | 40-70 | 160-210 | 3.0*2 | 3600 |
Overview:
The material enters the machine from the feeding port. Under the action of the vibration force, the material is thrown in the horizontal direction and moves forward continuously. The hot air passes through the fluidized bed and exchanges heat with the wet material. Discharge, the dry material is discharged from the discharge port.
The method of segmented heating is adopted. The pre-drying section adopts high pressure and low air volume fan, so that the wet material can be completely fluidized; the drying section adopts low pressure and high air volume fan, which can take away more water per unit time and dry evenly; the cooling section adopts The high air volume fan can quickly take away heat and reduce the temperature of the product, which not only meets the requirements of moisture control, but also facilitates the subsequent packaging process.
1. Drying medium circulation system: The blower, heater and air inlet pipe are made of stainless steel to avoid the possibility of product being polluted by unclean air.
2. The quick-opening structure is adopted between the upper and lower beds of the drying machine, which changes the bolt-fixed connection of the traditional structure, which greatly facilitates the thorough cleaning of the system.
3. The hole pattern of the material bed plate adopts a combined structure, and the front section adopts a tongue-shaped hole, so that the material can move forward smoothly without leakage; the middle and rear end adopt straight holes, the penetration rate of hot air is higher, drying The heat exchange of the process is more complete.
4. The lower bed is supported by stainless steel seamless steel pipe, the bed structure is stronger and the service life is long.
5. The interior of the lower bed is made of stainless steel fully welded to prevent sewage from entering the insulation layer during cleaning, thereby affecting the quality of the product, and a cleaning port is also provided to facilitate cleaning of the equipment.
Brief drawing
