Product Details:
|
| Name: | Horizontal Ribbon Mixer | Voltage: | Customized,380V,220V/380V,All Countries Are OK,3 P AC208-415V |
|---|---|---|---|
| Warranty: | 1 Year | Mixer Type: | Ribbon,double Ribbon Blender |
| Application: | Powder,Food Processing,Chemicals Processing,Medicine Processing,ribbon Blender Machine | Product Type: | Fertilizer,dry Powders,Detergent Powder,mixer,cosmetic |
| High Light: | Seasoning Powder Ribbon Mixer,2000L Powder Ribbon Mixer,Industrial Spice Powder Mixer |
||
Customizable 18kw 2000L industrial spice powder seasoning powder ribbon mixer
Horizontal Ribbon Mixer
Features:
1. Full welding at all connection parts.
2. All 304 stainless steel, and full mirror polished inside tank.
3. Special ribbon design makes no dead angle when mixing.
4. Patent Technology on double security shaft sealing.
5. Slightly concave flap controlled by pneumatic to achieve no leakage at discharge valve.
6. Round corner with silicone ring lid design.
7. With safety interlock, safety grid and wheels.
8. Slow rising keeps hydraulic stay bar long life.
Product information:
Horizontal ribbon blender is used to mix different powder, powder with liquid spray, powder with granule etc. Under the special design, the ribbon agitator makes the material to get a high effective convective mixing in short time.
Technical Parameters
| Model | WLDH-0.5 | WLDH-1 | WLDH-2 | WLDH-3 | WLDH-4 | WLDH-6 |
| Capacity (kg/batch) | 250 | 500 | 1000 | 1500 | 2000 | 3000 |
| Volume (L) |
500 | 1000 | 2000 | 3000 | 4000 | 6000 |
| Rotating (rpm) |
≤42 | ≤42 | ≤42 | ≤42 | ≤42 | ≤42 |
| Power (kW) |
5.5 | 11 | 18.5 | 22 | 30 | 37 |
| Dimension (cm) |
230*80*130 | 270*100*150 | 340*120*175 | 350*140*205 | 420*145*210 | 480*165*235 |
| Weight (kg) |
1000 | 1500 | 2300 | 3200 | 4100 | 5200 |
Application WLDH Series Horizontal Ribbon Mixer:
This machine is suitable for the mixing of viscous powders or granules with large load rate, small working area, large capacity and stable variety. Therefore, it is widely used in medicine, food, chemical industry, pesticides, plastics, dyes and other industries. It is also suitable for mixing dry powder materials such as milk powder, dry spices, seasoning powder, fertilizer powder, protein powder, etc. The machine is made of stainless steel and meets the food safety level.
FAR
Q:What factors I need to get a quotation?
A: Material information, required output. Product material requirements (carbon steel Q235A, stainless steel SUS304 or SUS316, etc.) also require voltage and frequency (Hz) to accurately quote.
Q:What is the real delivery time of your factory?
A: 25 days for general series products, meanwhile, batches products & customized products would need 30 days to 60 days based on different situations.
Q: How do you ensure the quality of your products?
A: Generally, our equipments are the most durable type in the industry. With our experienced quality control team, we are trying to offer most of our customers the product with bset quality. However, we do recognized that there do have small amount of the product which may got faulty or damaged for different reasons.
Q: What's your before & after service ?
A: 1) Professional advice and rich experience help to choose machine.
2) Longtime maintainance and considerate technical support
3) Technicians can be sent to abroad to install.
4)ONE year guarantee. WHOLE life service. Within1 year, any problem part can send to us, we can give provide free new part(only damaged by machine itself).
5) Any problem before or after delivery, you could find and talk with us anytime. We will free supply technical support.
6) Video / CD of test running and installation, Maunal book, tool box sent with machine if client request.
