CE 200-1000kg/H Universal Crusher WKS Professional Spice Grinder Electric

Basic Properties
Place of Origin: CHINA
Brand Name: xiaoli
Certification: CE
Model Number: WKS-50B
Trading Properties
Minimum Order Quantity: 1Set
Price: Negotiable
Payment Terms: T/T
Supply Ability: 10Sets Per Month
Product Summary
High Efficiency Easy-To-Operate Adjustable Mesh Profesional Spice Grinder Universal Crusher Technical Parameters Model WKS-20B WKS-30B WKS-40B WKS-50B WKS-60B Capacity (kg/h) 60-150 100-300 160-800 200-1000 300-1500 Shaft speed (r/min) 4500 3800 3400 3200 2800 Fineness size (mesh) 2-120 2-120 2-120 ...

Product Details

Highlight:

CE 1000kg/H Universal Crusher

,

CE 200kg/H Universal Crusher

,

WKS professional spice grinder electric

Name: Universal Crusher
Function: Grinding Material
Capacity: 200-1000kg/h
Feature: High Efficiency
Color: Silver
Fineness: 2-120 Mesh
MOQ: 1 Set
Warranty: 1Year
Product Description

High Efficiency Easy-To-Operate Adjustable Mesh Profesional Spice Grinder



Universal Crusher



Technical Parameters



Model WKS-20B WKS-30B WKS-40B WKS-50B WKS-60B
Capacity (kg/h) 60-150 100-300 160-800 200-1000 300-1500
Shaft speed (r/min) 4500 3800 3400 3200 2800
Fineness size (mesh) 2-120 2-120 2-120 2-120 2-120
Motor power (kW) 4 5.5 7.5 11 15
Weight (kg) 180 260 360 450 550
Dimension (mm) 550*600*1250 600*700*1450 750*800*1550 800*850*1600 1000*900*1680

CE 200-1000kg/H Universal Crusher WKS Professional Spice Grinder Electric 0

CE 200-1000kg/H Universal Crusher WKS Professional Spice Grinder Electric 1



Henan Workers Machinery Co., Ltd. produces dryers, granulators, pulverizers and packaging machines. The main products are exported to hundreds of countries and regions in Southeast Asia, South America, North America, Europe etc, and are well received by users all over the world! The company always adheres to the development strategy of "customer first, worry-free after-sales", pays attention to the reserve and training of talents, and has long-term exchange of talents and technologies with well-known enterprises at home and abroad. We aim to liberate people from heavy packaging production, let machines replace labor, reduce production costs and improve production efficiency.

The Universal Pulverizer may be widely applied in industries, such as medicine, chemical and food,etc.,for grinding of dry and fragile materials. Processing hard materials, including Chinese herbal spice etc. This machine utilizes the relative movement between the high-speed movable gear plate and the fixed gear plate, so that the crushed material can be crushed by the comprehensive effects of tooth impact, shear and friction, and material collision with each other. This WKS-30B universal crusher is a more popular crushing equipment. Its productive capacity can reach 100-300 kg per hour. If the customer wants to crush the materials more finely, they can contact us in time to understand the available crushing fineness before purchasing, so that we will match the suitable screen for the customer. If there are certain requirements for the temperature of the crushed materials, you can communicate in advance.



FAQ



Q: What's the capacity of the machine you need?

A: Like 50 kg/hr, 300 kg/hr,500 kg/hr..etc


Q: What is the real delivery time of your factory?
A: Finished product will be transported immediately after payment, meanwhile, customized products would need 10 to 30 working days based on different situations.

Q: How do you ensure the quality of your products?
A: Generally, our equipments are the most durable type in the industry, skilled workers and strict quality control system can ensure every machine with best working performance.



Q: What's the raw material you want to grind?

A: Like chili, sugar, Chinese herbs...etc


Q: What power do you use in your factory?-V,-Hz, 3 phase or single phase?

A: Like 220 V , 50 Hz , single or 380 V, 60 Hz , or customized
