OEM V Type Powder Mixer

Large Image : OEM V Type Powder Mixer

Product Details:

Place of Origin:	China
Brand Name:	WKS
Certification:	CE
Model Number:	WKS-V-1

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	negotiable
Packaging Details:	Normally it is packed in the plywood case, or loaded directly in the container after film wrapping
Delivery Time:	about 30 working days
Payment Terms:	T/T
Supply Ability:	10 sets for month

Contact Now

OEM V Type Powder Mixer

Description

Name:	V Type Power Mixer	Material:	SUS304
Application:	Powder	Certification:	CE Certificate
Function:	Mixer Blender	Product Type:	Powder And Granules
High Light:	OEM V Type Powder Mixer , ODM V Type Powder Mixer , WKS V Type Powder Mixing Machine

V Type Mixer to Mixing Pant Powders and Citric Acid Sodium Bicarbonate

V Type Powder Mixer

Products Description:

V series mixer is a mixing equipment for pharmaceutical industry and other powder and granular materials. It is widely used in pharmaceutical, food, chemical, and other industries. The equipment is designed based on the advantages of similar foreign products. Because the lengths of the two cylindrical columns that make up the mixer are not equal, they form an asymmetry. When the mixer is running, the materials are different from the decomposition and combination angles, forming an axial layer by layer Alternate diffusion and mixing, due to the different planes of the materials on the inner wall of the cylinder, also have different potential energy between each other, resulting in lateral convection mixing. The above-mentioned mixing effect is continuously repeated, so that the materials reach a very uniform random mixing state. Due to the internal gravity mixing, this machine has a small pressure feed to the material, high mixing uniformity, and is made of stainless steel material. The inner and outer walls are polished, and the power consumption and efficiency are high. It is an ideal device for the new generation of powder mixing.

The V type mixer adopts manual feed and closed disc valve discharge, which can avoid dust spilling; with unique mixing barrel structure, high efficiency blending and no dead angle, the materials can mix evenly. The inside and outside of the machine are polished. It is suitable for smaller powder, blocks and the material that contain a certain mixture of water. In addition, the machine is also equipped with a timing device; In that case, you can control the material mixing time.

Technical parameter


			TYPE
			FULL VOL.

			(m³)
			LOADING

			RATIO
			L

			(mm)
			W

			(mm)
			H

			(mm)
			DISCHARGE DIAMETER

			(mm)
			ROTATING HEIGHT

			(mm)
			ROTATING SPEED

			(rpm)
			ELECTRIC POWER

			(kW)
			WEIGHT

			(kg)


			WKS-V-0.1
			0.1
			0.4~0.8
			1650
			500
			1550
			φ80
			1600
			12
			0.75~1.1
			180


			WKS-V-0.3
			0.3
			0.4~0.8
			1900
			600
			1750
			φ100
			1900
			12
			1.1~1.5
			350


			WKS-V-0.5
			0.5
			0.4~0.8
			2300
			700
			2100
			φ150
			2250
			9
			1.5~2.2
			550


			WKS-V-1
			1
			0.4~0.8
			2700
			1000
			2500
			φ150
			2700
			9
			2.2~4
			1000


			WKS-V-1.5
			1.5
			0.4~0.8
			3000
			1000
			2600
			φ200
			2900
			8
			4~5.5
			1100


			WKS-V-2
			2
			0.4~0.8
			3200
			1200
			3100
			φ200
			3250
			8
			4~7.5
			1500


			WKS-V-2.5
			2.5
			0.4~0.8
			3950
			1500
			3550
			φ200
			3800
			7
			5.5~11
			1700


			WKS-V-3
			3
			0.4~0.8
			4100
			1500
			3600
			φ200
			3850
			6
			7.5~11
			1800



Application:
V mixer V blender is designed for mixing two or more dry power or granule raw materials,such as pharmaceutical industry, chemical industry,foodstuff industry and so on.

Main Features:

1. Mirror polished of inner and outer shell to meet cGMP standard.

2. No blind angle in the V-shells, no accumulation of materials, high speed I-bar, efficient and short mixing time.

3. Mixing uniformity can reach 99%

4. Rotating valve is equipped for discharging

5. Fully integrated motors and controls

6. Can work with vacuum feeding system to create dust-free working condition.


Pictures
