4000L Commercial Spice Coffee Powder Mixing Machine Ribbon Blender For Powder Mixing

Coffee Powder Commercial Spice Mixing Machine Stainless Steel Ribbon Mixer Horizontal

Horizontal Ribbon Mixer

Introduction

Powder food mixer is a new type of mixing equipment with high efficiency, high uniformity, high load factor, low energy consumption, low pollution and little destruction to frangible material.

Mixing moderate and high uniformity, mixing uniformity CV≤7%, no segregation.

Short mixing cycle(180-240s), large open layout, a quick feed, a small amount of residue.

Widely Application

It is mainly applies to food, feed, daily chemical, pesticides and other industries. Such as corn, chilli powder, spices, forage, flour, soybean powder, feed additives, etc

Technical Parameters


Working Principle

The horizontal ribbon mixer is under the action of the internal and external ribbons on the stirring shaft to turn the materials within the scope of the barrel. The inner spiral belt pushes the material from the middle to the sides of the cylinder, and the outer spiral belt pushes the material from the sides of the cylinder to the center. Convection circulation. Due to the agitation of the above movement, the materials are quickly and evenly mixed in a short time, so it is a high-efficiency mixing device with wide application, strong adaptability and good effect.

Features

1.It is suitable for mixing materials of powder-powder and power-liquid, especially for paste, powder and thick materials, such as putty, stone coatings, metal powders etc.

2.It is a new type of mixing equipment with high efficiency, high uniformity, high load factor, low energy consumption, low pollution and little destruction to frangible material.

3.The major sections of a mixer are barrel, ribbon agitators, feeding ports, discharging port and driven unit.

4.Double ribbon mixer drive the material from two ends to centre through the help of the outer ribbon, while the inner ribbon push the material from centre to two ends, thus, material achieve a high mixing effect at short time.

5.The ribbon mixer can be equipped with heating or cooling jacket if temperature control is required. We will add spraying or atomizing unit inside the tank.

Specifications Configuration

1.Optional Stirrer
a.Ribbon is suitable for powder and material with closing density, and needs more force during mixing.
b.Paddle suits granule like rice, nuts, beans etc. It’s also used to mix powder with big difference in density.

2.Material
Material options SS304 and SS316L. The surface treatment of stainless steel, including coated teflon, wire drawing, polishing and mirror polishing, can be used in different ribbon blender parts.

3.Discharge Type
The ribbon blender discharge valve can be driven manually or pneumatically. Optional valves: cylinder valve, butterfly valve etc.

4.Selectable Function
Ribbon blender sometimes needs to be equipped additional functions because of customer requirements, like jacket system for heating and cooling, weighing system, dust removal system, spray system and so on.

5.Optional
a.Adjustable speed: Powder ribbon blender machine can be customized into speed adjustable by installing a frequency converter.
b. Loading system: In order to make the operation of industrial ribbon blender machine more convenient, stairs for small model mixer, working platform with steps for larger model mixer, or screw feeder for automatic loading are all available.
c. Production line: Double ribbon blender can works with screw conveyor, hopper and auger filler to form production lines.

Pre-service

1. Introduce the product to the customer in detail, answer the question raised by customer carefully;
2. Make plans for choice according to the needs and special requirements of users in different sectors;

After-sale service

1. Assist clients to prepare for the first construction scheme;
2. Install and debug the equipment;
3. Train the first-line operators;
4. Examine the equipment;
5. Take initiative to eliminate the troubles rapidly;
6. Provide technical support;
7. Establish long-term and friendly relationship.
