Name: 304 Stainless Steel V Blender Dry Powder Mixer Aromatic Herbs Granules Mixing Machine
Brand: CHANGZHOU XIAOLI DRYING EQUIPMENT CO., LTD
SKU: WKS-V-0.5
Availability: InStock

Features Gallery Product Description Request A Quote

Features

Specifications

Name: V Type Power Mixer

Material: SUS304

Application: Powder

Certification: CE Certificate

Warranty: 1 Year

Usage: Powder Mixing

Highlight:

Stainless Steel V Blender Dry Powder Mixer

304SS v blender dry powder mixer

Aromatic Herbs Granules Mixing Machine

Basic Infomation

Place of Origin: China

Brand Name: xiaoli

Certification: CE

Model Number: WKS-V-0.5

Payment & Shipping Terms

Packaging Details: Normally it is packed in the plywood case, or loaded directly in the container after film wrapping

Delivery Time: about 30 working days

Payment Terms: T/T

Supply Ability: 10 sets for month

Gallery

304 Stainless Steel V Blender Dry Powder Mixer Aromatic Herbs Granules Mixing Machine

Product Description

304 Stainless Steel Powder V Blender Mixer for Dry Granule Aromatic Herbs

V Type Powder Mixer

Introduction

V-type mixer is produced based on our own advanced technology, widely used in pharmaceutical, food, chemical, building materials industry, paint, condiment and other industries.

Features

1. Using the principle of gravity diffusion, the pressure to the material is small, will not cut the material.

2. Cylinder made of high quality stainless steel, the inner and outer walls are polished, the process of mixing materials without pollution, power consumption is small, easy to clean.

3. Using stainless steel butterfly valve discharge, no dust leakage and flying phenomenon.

4. Large-capacity mixer can be configured with vacuum feeding system to improve work efficiency and improve the working environment.

5. Especially suitable for the materials with similar particle size and apparent density, also can be used for materials which are easy to aggregate.

Operation and Maintenance

1. Connect the power first, setting the required mixing time, then turn on the switch, the machine begin running.

2. After the mixing, if you found that the position of discharging port is not the best position, you should turn off the power first, and adjust the position of discharging port.

3. Before you use the machine, you should check the appliance, if it is normal; and check the covers of mixing barrels, if the covers are tightly closed.

4. User should clean the machine after the finish of work, especially the barrels, prevent the residual materials.

5. Note that the reducer should be added enough lubricating oil(generally use the 30 # machine oil), and the transmission should be added grease lubricant.

6. Users should maintain the machine once each half of year, change the lubricating oil of reducer, check if the appliance is aging, the appliance should be replaced if it is aging.

7. After you have been using the machine for one year or more, you should make a big maintenance, check the gab between each parts, and appropriately adjust them, so that the machine can keep in good condition.

Main Usage

This mixer is used for mixing dry granules materials for pharmacy or other relative industries.

Specialty

Unique structure of mixing cylinder,high mixing effciency,free of dead corner,and even mixing.

Technical parameter


			TYPE
			FULL VOL.

			(m³)
			LOADING

			RATIO
			L

			(mm)
			W

			(mm)
			H

			(mm)
			DISCHARGE DIAMETER

			(mm)
			ROTATING HEIGHT

			(mm)
			ROTATING SPEED

			(rpm)
			ELECTRIC POWER

			(kW)
			WEIGHT

			(kg)


			WKS-V-0.1
			0.1
			0.4~0.8
			1650
			500
			1550
			φ80
			1600
			12
			0.75~1.1
			180


			WKS-V-0.3
			0.3
			0.4~0.8
			1900
			600
			1750
			φ100
			1900
			12
			1.1~1.5
			350


			WKS-V-0.5
			0.5
			0.4~0.8
			2300
			700
			2100
			φ150
			2250
			9
			1.5~2.2
			550


			WKS-V-1
			1
			0.4~0.8
			2700
			1000
			2500
			φ150
			2700
			9
			2.2~4
			1000


			WKS-V-1.5
			1.5
			0.4~0.8
			3000
			1000
			2600
			φ200
			2900
			8
			4~5.5
			1100


			WKS-V-2
			2
			0.4~0.8
			3200
			1200
			3100
			φ200
			3250
			8
			4~7.5
			1500


			WKS-V-2.5
			2.5
			0.4~0.8
			3950
			1500
			3550
			φ200
			3800
			7
			5.5~11
			1700


			WKS-V-3
			3
			0.4~0.8
			4100
			1500
			3600
			φ200
			3850
			6
			7.5~11
			1800


Pictures
