Product Details:
|
| Name: | Microwave Vacuum Dryer | Application: | Pineapple Mango Fruits |
|---|---|---|---|
| Function: | Dry And Dehydration | Feature: | Low Temperature And High Efficiency |
| Microwave Power: | 24kw | Capacity: | 200-300kg/h |
| High Light: | 24kw Commercial Microwave Vacuum Dryer,24kg/h Microwave Vacuum Dryer,Pineapple Mango Dehydrator Oven |
||
Commercial Microwave Vacuum Dryer Drying Oven Dehydrator for Pineapple Mango Fruits
Microwave Vacuum Dryer
Microwave vacuum drying equipment is a new type of microwave energy application equipment combining microwave energy technology and vacuum technology. It has a series of advantages of microwave and vacuum drying, and overcomes the shortcomings of conventional vacuum drying cycle and low efficiency. In the drying process, the work efficiency can be improved by 4 to 10 times compared with the conventional method. Microwave vacuum drying equipment is a comprehensive high-tech equipment combining microwave energy application technology and vacuum drying technology condensation and dehumidification technology. It is mainly used for low temperature dehydration of fruits, vegetables and food etc.
| Model | WKS-MV-3 | WKS-MV-6 | WKS-MV-9 | WKS-MV-12 | WKS-MV-24 | WKS-MV-48 |
| Microwave power | 3kw | 6kw | 9kw | 12kw | 24kw | 48kw |
| Frequency | 2450±50MHz | 2450±50MHz | 2450±50MHz | 2450±50MHz | 2450±50MHz | 2450±50MHz |
| Evaporation capacity | 2.4-3kg/h | 4.8-6kg/h | 7.2-9kg/h | 9.6-12kg/h | 19.2-24kg/h | 38.4-48kg/h |
| Cooling | Air | Air | Air | Air | Air/water | Air/water |
| Vacuum pump | 1.8kw | 2.2kw | 2.2kw | 4.5kw | 7.5kw | 15kw |
| Control | PLC+HMI | PLC+HMI | PLC+HMI | PLC+HMI | PLC+HMI | PLC+HMI |
The fruit after drying by the microwave vacuum dryer is beautiful in color, plump in pulp, and the nutrients are preserved. The fruits dried by microwave vacuum dryer have the advantages that other drying and drying do not have: the drying speed is fast, it only takes about 2-3 hours to dry a batch of fruits, the drying temperature is low, the drying temperature only needs about 45 degrees, and the heating and drying are uniform.
Using the tube condensation recovery system, the steam and water vapor can be recovered and eliminated in time. The microwave vacuum dryer is more energy-saving, has faster drying speed, lower energy consumption, and the drying time is shortened from 4 hours to 3 hours.
The vacuum system dehumidifies efficiently, removes the water vapor generated during microwave heating and drying in time, and prevents the steam from fumigating the fruit and causing the color of the material to change.
Automatic, visual operation, easy to operate.
FAQ:
1. Question: What information should be provided in order to get a quotation of microwave vacuum dryer?
Answer: Our Sintering oven can be customerized. Before we can work out a detailed quotation, we have to know the following information:
1) What are you going to dry?
2) What is the handing capacity per batch?
3) Max temperature, heat-up rate, temperature uniformity.
2. Question: What is lead time?
Answer: 30-45 working day.
3. Question: How the dryer will be delivered ?
Answer: FOB LCL or FLC for shipping
5.Question: What standard models do you have?
Answer: We have the following standard models:
