Product Details:
|
| Name: | WKS Series Vacuum Microwave Dryer | Model: | WKS-MV-9 |
|---|---|---|---|
| Application: | Food Fruit Vegetable | Capacity: | 100-300kg/batch |
| Materials: | 304 Stainless Steel | Vacuum: | -0.95Mpa |
| Microwave Power: | 9kw | ||
| High Light: | Air Cooling Fruit And Vegetable Dryer,9KW fruit and vegetable dryer,Vacuum Microwave Drying Oven |
||
Fruits and Vegetables Vacuum Microwave Dryer Drying Oven Machine Equipment
Vacuum Microwave dryer
Working principle
There is a direct relations between evaporation temperature andatmospheric pressure during vacuum drying oven processing, the lower the atmospheric pressure, the lower the boiling point of water. In an atmosphere,the water boiling point is 100°C.Therefore, we can dry the material under the low temperature under thevacuum conditions.
Deliver of this power will be not affect underthe vacuum conditions.Then the efficiently will be high absolutely.Also that canavoid this problem that is only the surface is dry and the gas can be dischargedeasily.
Raw material can be heated quickly by microwave heating. The energyconsumption of this kinds machine can reduce more than 10% compare with sametype machine.Therefore, it has high quality, low cost, high yield, high efficiency,stable equipment operation, etc.
| Model | WKS-MV-3 | WKS-MV-6 | WKS-MV-9 | WKS-MV-12 | WKS-MV-24 | WKS-MV-48 |
| Microwave power | 3kw | 6kw | 9kw | 12kw | 24kw | 48kw |
| Frequency | 2450±50MHz | 2450±50MHz | 2450±50MHz | 2450±50MHz | 2450±50MHz | 2450±50MHz |
| Evaporation capacity | 2.4-3kg/h | 4.8-6kg/h | 7.2-9kg/h | 9.6-12kg/h | 19.2-24kg/h | 38.4-48kg/h |
| Cooling | Air | Air | Air | Air | Air/water | Air/water |
| Vacuum pump | 1.8kw | 2.2kw | 2.2kw | 4.5kw | 7.5kw | 15kw |
| Control | PLC+HMI | PLC+HMI | PLC+HMI | PLC+HMI | PLC+HMI | PLC+HMI |
Functions:
1.High Efficiency, this processing speed is four times higher than normal drying processing.
2.Uniform Heating: The machine comes with Camera for production monitoring, the machine is Micro Wave for heating, So the inner and outer of the raw material will be heated at same time. Then the heating and drying will be very uniform.
3.Easily Controlling: Because of the Micro Wave Heating, so the machine can work continuously. And the power of Micro Wave is easy adjusting without any inertia, so the processing is easy operation and easily controlling. All of the data for Micro Wave can be set by Touch screen.
Application
1.The flavorings spice.
2.Subsidiary agricultural products, deep processing products of fruit, vegetable.
3.Various dried meat, like beef, pork, chicken,duck, fish, etc.
4.The grain, the deep manufactured products.
5.Sterilization of beverage and the wine, the meat, the marine product, the roasted seeds and nuts, and etc.
6.Chemical material,medicine tablet.
7.Powder for various material.
FAQ:
1. Question: What information should be provided in order to get a quotation of microwave vacuum dryer?
Answer: Our Sintering oven can be customerized. Before we can work out a detailed quotation, we have to know the following information:
1) What are you going to dry?
2) What is the handing capacity per batch?
3) Max temperature, heat-up rate, temperature uniformity.
2. Question: What is lead time?
Answer: 30-45 working day.
3. Question: How the dryer will be delivered ?
Answer: FOB LCL or FLC for shipping
5.Question: What standard models do you have?
Answer: We have the following standard models:
