100L to 10000L Dry Powder Horizontal Ribbon Mixer Double Helix Industrial Powder Liquid Ribbon Mixer
Horizontal Ribbon Mixer
Mixing Principle:
When the material feeds into the mixing tank, the outer ribbon make the material move from the sides to the center, and the inner ribbon moves the material move from the center to the sides. So the material in the U-tank will get the complete mixing in a short time.
Application:
Food and pharmaceutical industry: flavor, spice, seasoning, flour, milk powder, coffee, bakery powder, protein powder, medical intermediate, etc. Chemical industry: fertilizer, animal feed, fodder, pesticide, putty powder, wall putty powder, gypsum powder , dry mortar, dry cement, colorant, reactive dyes, putty, anticrack sludge, etc.
Technical Parameters
| Model | WLDH-0.5 | WLDH-1 | WLDH-2 | WLDH-3 | WLDH-4 | WLDH-6 |
| Capacity (kg/batch) | 250 | 500 | 1000 | 1500 | 2000 | 3000 |
| Volume (L) |
500 | 1000 | 2000 | 3000 | 4000 | 6000 |
| Rotating (rpm) |
≤42 | ≤42 | ≤42 | ≤42 | ≤42 | ≤42 |
| Power (kW) |
5.5 | 11 | 18.5 | 22 | 30 | 37 |
| Dimension (cm) |
230*80*130 | 270*100*150 | 340*120*175 | 350*140*205 | 420*145*210 | 480*165*235 |
| Weight (kg) |
1000 | 1500 | 2300 | 3200 | 4100 | 5200 |
Company introduction
Henan Workers Machinery Co., Ltd. (hereinafter referred to as WKS), established for more than 10 years, is committed to the research, manufacturing and sales of various industrial drying machines, fruits & vegetables and food processing machines, also one of the earliest manufacturers involved in industrial drying equipment in China.
WKS has a modern standard workshop, covering over 2,000 square meters; WKS more than 50 professional engineers from a different technical background with many years of rich research and manufacturing experiences. WKS mainly manufactures industrial microwave dryer, hot air circulation dryer, multi-layer belt hot air dryer, vibratory fluidized bed drying equipment, spray dryer and other fruits & vegetables and food processing machines; all of our products are made of high quality stainless steel with mature product design and sophisticated production technology.
Therefore, high-quality products have much easier access to a good market reputation and share. Our products are exported to dozens of countries such as the United States, Canada, Britain, France, Australia, South Korea, India, Singapore, Thailand, Malaysia, Sri Lanka, Brazil, Russia, Uzbekistan, Romania, Croatia, Latvia, Sweden, Nigeria and South Africa, etc.
WKS believes in customer-oriented business and "quality first" philosophy, so WKS focuses on providing customers with high quality, competitive prices and wholehearted services.
Welcome to visit us to start the cooperation!
Main Features:
1) Horizontal tank body, need small space but more capacity.
2) Dual screw structure-The inner screw push the material form central to sides and the outer screw push the material from sides to the center to make the material effective mixing.
3) Gear box drive the auger shaft , low noise and low malfunction, long using life.
4) U-Shape tank bottom, better for material discharge and cleaning.
5) Pneumatic cylinder to control the discharge exit.
6) Air cylinder help the top cover easy open.
7) Heating, cooling function can be realized.
8) Customized ribbon blender available.
9) PLC controlled, equipped with mettler toledo weigh modular.
