SS304 Seasoning Vacuum Freeze Drying Machine Cold Brew Coffee Dryer Machine
Product Details
Seasoning Vacuum Freeze Drying Machine
,SS304 vacuum freeze drying machine
,Cold Brew Coffee Dryer Machine
Seasoning Freeze Drying Machine Cold Brew Coffee Vacuum Dryer
Vacuum Freeze Dryer
Characteristics
1. Perfect appearance, compact size;
2. Touch screen operation, one key to start, and automatic freeze drying process, easy and convenient;
3. Key components with imported brands, small noise, large capacity, high quality and high performance;
4. Advanced system, with low operating current and low energy consumption;
5. 304 stainless steel food tray and inside liner, safety and easy clean;
6. Transparent organic glass door, the direct observation of food processing;
Technical parameters
| Model | FD-1C | FD-5C | FD-10C | FD-20C | FD-30C | FD-50C |
| Control method | PLC touch screen | |||||
| Working methods | quick freezing, lyophilization | |||||
| Material | SUS304 | |||||
| Drying area (sqm) | 1 | 5 | 10 | 20 | 30 | 50 |
| Loading capacity(kg) | 10 | 50 | 100 | 200 | 300 | 500 |
| Tray size (mm) | 400*500*25 | 600*1000*25 | 800*1000*25 | 600*1000*25 | 800*500*20 | 600*1000*20 |
| Tray pcs | 5 | 9 | 13 | 34 | 76 | 80 |
| Tray form | SUS304, perforated or solid tray | |||||
| Shelf | 8 | 13 | 18 | 38 | 40 | 86 |
| Shelf temperature(°C) | -55~120 | |||||
| Shelf medium | low temperature silicone oil | |||||
| Vacuum pump | Rotary vane pump | two-level pump | combined pump | |||
| Working vacuum(pa) | ≦130 | |||||
| Ultimate vacuum(pa) | <10 | |||||
| Defrosting method | hot water spray | hot water soaking | ||||
| Compressor | Copeland | |||||
| Power | custom | |||||
| Working environment temperature(°C) | ≦ 40 | |||||
| Rated power(kW) | 6 | 16 | 28 | 56 | 70 | 110 |
| Size (mm) | 2000*700*1700 | 3000*1500*1800 | 3200*1600*2100 | 5000*2200*2500 | 6000*2600*2900 | 9000*3800*3500 |
The vacuum freeze drying machine is an advanced method for the material for the material de-watering. It freezes the moisture material in the low temperature and makes the water inside sublimate directly in the vacuum condition. Then it collects the sublimated vapor by means of the condensing way so as to dewater and dry the material. The processed material can be recovered quickly if being watered again.
Before the large scale production, small sized pilot freeze dryer is used to get the data curve of freeze drying process. All the data about temperature, pressure inside the chamber and the weight of the drying material is saved in computer, which is the guidance of real mass production, and it’s also suitable for universities, institutes and other organizations for samples and crafts research or process testing, especially suitable for small production with high value-added. LCD display makes it more clear to monitor the whole process, the pre-set curve can be revised in order to achieve the optimization of process options.
-
