Product Details:
|
| Name: | Microwave Vacuum Dryer | Model: | WKS-MV-48 |
|---|---|---|---|
| Capacity: | 100-200kg/batch | Drying Time: | 2-3 Hours/batch |
| Vacuum: | 0.92Mpa | Material: | 304 Stainless Steel |
| High Light: | WKS Low Temperature Vacuum Dryer,Microwave Vacuum Drying Chamber,Vacuum Drying Chamber For Plant Extract |
||
Low Temperature Vacuum Dryer Microwave Vacuum drying chamber for Plant Extract
Microwave Vacuum dryer
Microwave vacuum drying plant extract features:
(1) Low drying temperature, suitable for drying heat-sensitive plant extract paste;
(2) Suitable for drying plant extracts that are prone to oxidation;
(3) Suitable for drying plant extracts with high concentration and high viscosity;
(4) The product has good solubility. After drying, the material can be seen to have micropores in the microstructure. After being directly crushed to the required particle size, the fluidity of the particles is very good. excellent sex;
(5) During the drying process, the product is always in a vacuum state, which reduces the oxidation of the product and makes the material not easy to stick. Keep the original color, aroma and taste to the greatest extent, and get the final product of high quality.
| Model | WKS-MV-3 | WKS-MV-6 | WKS-MV-9 | WKS-MV-12 | WKS-MV-24 | WKS-MV-48 |
| Microwave power | 3kw | 6kw | 9kw | 12kw | 24kw | 48kw |
| Frequency | 2450±50MHz | 2450±50MHz | 2450±50MHz | 2450±50MHz | 2450±50MHz | 2450±50MHz |
| Evaporation capacity | 2.4-3kg/h | 4.8-6kg/h | 7.2-9kg/h | 9.6-12kg/h | 19.2-24kg/h | 38.4-48kg/h |
| Cooling | Air | Air | Air | Air | Air/water | Air/water |
| Vacuum pump | 1.8kw | 2.2kw | 2.2kw | 4.5kw | 7.5kw | 15kw |
| Control | PLC+HMI | PLC+HMI | PLC+HMI | PLC+HMI | PLC+HMI | PLC+HMI |
Vacuum microwave equipment is a new concept with high efficiency and energy saving. It has been successfully used in the drying of Salvia miltiorrhiza extract, Panax notoginseng extract, Angelica extract and food malt extract, coffee, milk powder, etc., and obtained good results. For food, due to its short drying time, low temperature, no oxidation in vacuum state, and good retention of aroma; in the field of pharmaceuticals, it has good retention activity for some active substances, APIs, heat-sensitive substances, vitamins, and aromatic substances. and fragrance effects.
Microwave vacuum drying equipment is a new type of microwave energy application equipment combining microwave energy technology and vacuum technology. It has a series of advantages of microwave and vacuum drying, and overcomes the shortcomings of conventional vacuum drying cycle and low efficiency. In the drying process, the work efficiency can be improved by 4 to 10 times compared with the conventional method. Microwave vacuum drying equipment is a comprehensive high-tech equipment combining microwave energy application technology and vacuum drying technology condensation and dehumidification technology. It is mainly used for low temperature dehydration of fruits, vegetables and food etc.
FAQ:
1. Question: What information should be provided in order to get a quotation of microwave vacuum dryer?
Answer: Our Sintering oven can be customerized. Before we can work out a detailed quotation, we have to know the following information:
1) What are you going to dry?
2) What is the handing capacity per batch?
3) Max temperature, heat-up rate, temperature uniformity.
2. Question: What is lead time?
Answer: 30-45 working day.
3. Question: How the dryer will be delivered ?
Answer: FOB LCL or FLC for shipping
5.Question: What standard models do you have?
Answer: We have the following standard models:
