30kw Shrimp Seafood Seaweed Belt Dryer Continuous Microwave Drying Machine

Shrimp and Seafood Seaweed Continuous Microwave Belt Dryer Drying and Sterilizing Machine

Industrial Drying Machine

Microwave drying is a new drying method. When drying, the microwave energy directly acts on the medium molecules and converts it into heat energy. Due to the penetrating property of the microwave, the medium can be heated at the same time without heat conduction, so the heating speed is very fast, and the drying speed can be shortened for foods with a water content below 30%. hundreds of times. At the same time, regardless of any shape of the object, due to the simultaneous heating of the medium inside and outside the object, the temperature difference between the inside and outside of the material is small, the heating is uniform, and the condition of external coke endogenous in conventional heating will not occur, which greatly improves the drying quality.

Working Principle:
Microwave is a sort of electromagnetic wave which frequency is 300GHZ. The water molecule in medium material is polar molecule, under the effect of the repaid change of electromagnetic field, it is polarity orientation will alter with the changes of external electric field with high-speed, causing the movements and friction of molecule, so that the microwave field energy can be converted to heat energy in medium to rise the temperature of materials, accomplishing heating, puffing and a series of physical processes and so microwave is achieved.

The microwave dryer has the function of thawing, sterilizing, curing, and drying. The color and nutritional content of the material remain unchanged. The drying time is fast. It is used to dry food medicinal materials, wood, building materials, cardboard.

Features:

1. The equipment can be used in two ways, manual and automatic circulation.
2. The box body is made of 1.5mm thick 304 stainless steel plate, which is sturdy and durable.
3. Microwave power: ≥30kw, total power ≥40kw.
4. The function of preventing the equipment from being turned on by mistake to protect the equipment.
5. Digital variable frequency sealed microwave power supply, which can save energy by 20%.
6. The equipment and electrical appliances are equipped with voltage stabilizing device, integrated design, and the operation is more durable and stable.
7. The equipment structure is reasonable, the heating is uniform, and the sterilization effect is better. The uniformity and practicability of domestic manufacturers are about 10% higher than that of domestic manufacturers.
8. Teflon conveyor belt, thick mesh belt, high temperature resistance, corrosion resistance, no fire.
9. Temperature monitoring system.

10.  Equipment, machinery and electrical safety standards, microwave leakage standards, are strictly implemented in accordance with national standards, and all have EU CE certification.

FAQ:

1. Question: What information should be provided in order to get a quotation of microwave vacuum dryer?
Answer: Our Sintering oven can be customerized. Before we can work out a detailed quotation, we have to know the following information:
1) What are you going to dry?
2) What is the handing capacity per batch?
3) Max temperature, heat-up rate, temperature uniformity.

2. Question: What is lead time?
Answer: 30-45 working day.

3. Question: How the dryer will be delivered ?
Answer: FOB LCL or FLC for shipping

4.Question: What standard models do you have?
Answer: We have the following standard models:
