Product Details:
|
| Name: | Pumpkin Sunflower Seeds Walnuts Nuts Continuous Tunnel Microwave Dryer Sterilizer Machine | Model: | WKS-BM-60 |
|---|---|---|---|
| Evaporation Capacity: | 48-60kg/h | Cooling: | Water Cooling |
| Microwave Power: | 60kw | Materials: | 304 Stainless Steel |
| High Light: | 60kg/H Microwave Tunnel Oven,Kava Powder Microwave Tunnel Oven,48kg/H Industrial Drying Machine |
||
Pumpkin Sunflower Seeds Walnuts Nuts Continuous Tunnel Microwave Dryer Sterilizer Machine
Industrial Drying Machine
Drying principle
The direct interaction between the material and the microwave, the polar molecules (water molecules, etc.) in the material absorb the microwaves and change the original molecular structure under the action of the microwaves to exhibit the directional arrangement; the polar molecules conduct the polarity movement according to the change of the external electromagnetic field, And the same frequency with the microwave frequency friction heat generated, so that the rapid increase in temperature within a short time from the material to achieve the heating and curing effect, to achieve the purpose of rapid drying dehydration.
| Model | WKS-BM-12 | WKS-BM-20 | WKS-BM-30 | WKS-BM-50 | WKS-BM-60 | WKS-BM-80 |
| Microwave power | 12kw | 20kw | 30kw | 50kw | 60kw | 80kw |
| Frequency | 2450±50MHz | 2450±50MHz | 2450±50MHz | 2450±50MHz | 2450±50MHz | 2450±50MHz |
| Evaporation capacity | 9-12kg/h | 16-20kg/h | 24-30kg/h | 40-50kg/h | 48-60kg/h | 64-80kg/h |
| Cooling | Air | Air | Air | Air | water | water |
| Control | PLC+HMI | PLC+HMI | PLC+HMI | PLC+HMI | PLC+HMI |
PLC+HMI |
2.Sterilization principle
Material in the microwave heating process simultaneously biological effect. Under the action of microwave, the harmful bacteria, pests and other microorganisms in the material are subjected to the action of non-polar thermal and polar rotation to change the arrangement and movement of microorganisms, so that the organism is inactivated due to the deterioration of the protein and Relaxes, breaks or recombines several hydrogen bonds of RNA and DNA, interferes or destroys its normal metabolism, heredity and proliferation, inhibits or causes the growth of dead cells and pests, Sterilization, preservation purposes.
Application
FAQ:
1. Question: What information should be provided in order to get a quotation of microwave vacuum dryer?
Answer: Our Sintering oven can be customerized. Before we can work out a detailed quotation, we have to know the following information:
1) What are you going to dry?
2) What is the handing capacity per batch?
3) Max temperature, heat-up rate, temperature uniformity.
2. Question: What is lead time?
Answer: 30-45 working day.
3. Question: How the dryer will be delivered ?
Answer: FOB LCL or FLC for shipping
4.Question: What standard models do you have?
Answer: We have the following standard models:
