Product Details:
|
| Name: | Vacuum Freeze Dryer | Voltage: | Depends On Local Voltage |
|---|---|---|---|
| Condition: | New | Warranty: | 1 Year |
| Type: | Freeze Drying Equipment | After-sales Service Provided: | Engineers Available To Service Machinery Overseas,Video Technical Support |
| Application: | Food Processing,Medicine Processing,Chemicals Processing | Material: | Stainless Steel,SS304 |
| High Light: | Jackfruit Vacuum Freeze Dryer,Strawberry Vacuum Freeze Dryer,WKS Potato Chips Drying Machine |
||
Fruit and Vegetable Chips Yogurt Strawberry Jackfruit Vacuum Freeze Dryer
Vacuum Freeze Dryer
Vacuum freeze-drying technology is applied to process food material to make freeze dried food. The freeze dryer is used in all conceivable kinds of agricultural products with top drying quality.
Fruits:
durian, strawberry, mango, apricot, kiwifruit, pineapple, lemon, raspberry, avocado, banana
Vegetables:
broccoli, parsley, mushroom, bean, scallion, asparagus, onion, celery, carrot, tomato, pepper etc.
Other food:
beef, coffee, colostrums, herbal, flower, tea, honey, sea food and all kinds of pets food.
Characteristics
1. Perfect appearance, compact size;
2. Touch screen operation, one key to start, and automatic freeze drying process, easy and convenient;
3. Key components with imported brands, small noise, large capacity, high quality and high performance;
4. Advanced system, with low operating current and low energy consumption;
5. 304 stainless steel food tray and inside liner, safety and easy clean;
6. Transparent organic glass door, the direct observation of food processing;
Technical parameters
| Model | FD-1C | FD-5C | FD-10C | FD-20C | FD-30C | FD-50C |
| Control method | PLC touch screen | |||||
| Working methods | quick freezing, lyophilization | |||||
| Material | SUS304 | |||||
| Drying area (sqm) | 1 | 5 | 10 | 20 | 30 | 50 |
| Loading capacity(kg) | 10 | 50 | 100 | 200 | 300 | 500 |
| Tray size (mm) | 400*500*25 | 600*1000*25 | 800*1000*25 | 600*1000*25 | 800*500*20 | 600*1000*20 |
| Tray pcs | 5 | 9 | 13 | 34 | 76 | 80 |
| Tray form | SUS304, perforated or solid tray | |||||
| Shelf | 8 | 13 | 18 | 38 | 40 | 86 |
| Shelf temperature(°C) | -55~120 | |||||
| Shelf medium | low temperature silicone oil | |||||
| Vacuum pump | Rotary vane pump | two-level pump | combined pump | |||
| Working vacuum(pa) | ≦130 | |||||
| Ultimate vacuum(pa) | <10 | |||||
| Defrosting method | hot water spray | hot water soaking | ||||
| Compressor | Copeland | |||||
| Power | custom | |||||
| Working environment temperature(°C) | ≦ 40 | |||||
| Rated power(kW) | 6 | 16 | 28 | 56 | 70 | 110 |
| Size (mm) | 2000*700*1700 | 3000*1500*1800 | 3200*1600*2100 | 5000*2200*2500 | 6000*2600*2900 | 9000*3800*3500 |
What Features of our food freeze dryer
Freeze dryer known as lyophilizer, is the machine to dry different types of material to prolong its preservation time. There are many kinds of dryers; freeze dryer is the best dryer to make high quality dried products. It is quite different from dehydrator, drying oven, microwave heating, and vacuum heating drying. Drying needs heat, with those kinds of drying method, heating is in room temperature, so it has harmful to material, and there is huge nutrition and biological activity loss in the drying procedure.
On the contrary, by freeze drying, heating is occurred after the material is completely frozen to -40 C, and material is in frozen status in the whole drying procedure till completely dried. Therefore, the freeze dried products preserve its original shape, color and it has no biological activity loss, no nutrition loss. Freeze dryer is suitable for food industry, pharmaceutical industry, chemical industry and laboratory test.
Full range of freeze dryers provided: the small unit is for laboratory and home use; the medium-sized is for food and pharmaceutical drying application; the large-sized freeze dryer is for food and chemical industry which requires mass production by economic equipment with lower energy consumption. We focus on manufacturing freeze dryer for 10 years with rich installation experience in home and abroad.
